Year of manufacture 2023
Working dimension X 3.117 mm
Working dimension Y 2.177 mm
Working dimension Z 150 mm
Number of milling spindles 1
Blow-off device
Main motor power 14 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 18
SCM Tool changer FAST 18
Vertical drilling spindles 12
SCM Drilling aggregate F 20 LL
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in Y-direction, in X-direction
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Matrix table
Multi-zone vacuum
Positioning aid
Point-type laser
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 500 m³/h
Suitable for nesting
Labelling automatic
Barcode reader
Safety device Bumper
SCM Pro-Space
Interface for .dxf data
SCM TecPad
Workpiece length measurement
Werkstückdickenmessung
Unloading unit
Automatic central lubrication
Control cabinet cooling
Control SCM eye-M PRO
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/62471
2025-04-02 20:58:05
- Germany
- Second hand
