Year of manufacture 2019
Working dimension X 4.286 mm
Working dimension Y 2.185 mm
Working dimension Z 150 mm
Number of milling spindles 1
Main motor power 15 kW
Milling spindle liquid-cooled
Rotation speed max 24.000 rpm
Torque support
Tool clamping system HSK-F63
Tool changer positions 20
Pickup change place
SCM Tool changer TR
Vertical drilling spindles 12
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
SCM Drilling aggregate F 18 L
Gantry machine Yes
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 3
Capacity vacuum pump 750 m³/h
Suitable for nesting
Feeding Lift table
Outfeed Conveyor belt
Labelling manually
Barcode reader
Safety device Bumper
Interface for .dxf data
SCM Machine table HE Multi function table
Tool charge measurement
Barcode reader
SCM TecPad
Milling spindle liquid-cooled
SCM Tool changer TR
Pickup tool changer
Automatic central lubrication
Control SCM eye-M
Software SCM PANELMAC, SCM MAESTRO CNC, SCM MAESTRO NEST
Conformity marking CE mark
Weight 7.400 kg
Technical data are partly estimated. Actual values may differ.
https://www.hoechsmann.com/93691
2025-04-02 17:29:29
- Germany
- Second hand
