Year of manufacture 2024
Working dimension X 2.600 mm
Working dimension Y 900 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 4,5 kW
Rotation speed max 24.000 rpm
Tool clamping system Collet
Vertical drilling spindles 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
BIESSE Drilling aggregate BH 17 L
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device Safety mat, enclosed cabin
Control PC control
Software BIESSE B_SOLID, BIESSE SOPHIA
Conformity marking CE mark, UKCA-Zeichen
Total connection 12 kW
Weight 1.800 kg
Space requirement Length 2,8 m
Space requirement Width 1,94 m
Space requirement Height 2 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
