Year of manufacture 2010
Working dimension X 4.469 mm
Working dimension Y 1.350 mm
Working dimension Z 180 mm
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 20.000 rpm
4th axis Yes
5th axis 5-axes spindle
Milling spindle liquid-cooled
Tool clamping system HSK-F63
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 8
Positioning aid
Crosshair laser
Safety device Bumper
Chip conveyor
Interface for .dxf data
Handheld terminal
Workpiece support aids
Tool charge measurement
Automatic central lubrication
Control PC control
Software SCM XILOG PLUS
Conformity marking CE mark
Weight 3.500 kg
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/13754
2025-03-12 20:34:22
- Germany
- Second hand
