Year of manufacture 2019
Working dimension X 3.050 mm
Working dimension Y 850 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 10 kW
Rotation speed max 24.000 rpm
Tool clamping system ETP 25
Tool changer positions 4
Vertical drilling spindles 13
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Milling for fittings Lamello Clamex
Interface for .dxf data
Control HOMAG POWER CONTROL V2, Homag powerTouch
Software HOMAG WOODWOP, HOMAG WOODWOP LAMELLO CLAMEX
Total connection 11,5 kW
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/33501
2024-08-27 08:48:35
- Germany
- Second hand
