Numerical Control Biesse Bh 660 with Biesse Works Advanced Software
Working range in X axis mm 3060
Working range in Y axis mm 1320
Working range in Z axis mm 150
No. 2 working fields
Work table with bars
No. 6 electronically adjustable bars (EPS system) - for the suction cup support
No. 4 pneumatic bakelite bars for lifting the panel
No. 3 electronically adjustable suction cups (EPS system) for each bar with vacuum seal for fixing the panel during processing
No. 1 vertical electrospindle with C axis, with automatic tool change, KW 12 motor, Hsk type cones
Automatic tool change system with no. 24 positions - positioned on the back of the machine
Drilling head with no. 20 spindles arranged as follows:
- No. 7 vertical in X axis
- No. 7 vertical in Y-axis
- No. 4 horizontal in X-axis
- No. 2 horizontal in Y-axis
Independent blade for making grooves in X-axis
Front protection and safety system with belts
Perimeter protection grids
Automatic lubrication system
Conditioning system for cooling and cleaning the machine control
Vacuum pump mc/h 250
- Italy
- Second hand
