Year of manufacture 2019
Working dimension X 3.000 mm
Working dimension Y 920 mm
Working dimension Z 50 mm
Number of milling spindles 1
Main motor power 3,6 kW
Rotation speed max 24.000 rpm
Tool clamping system ISO 30
Vertical drilling spindles 9
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Machine table Feed-through technology
Feedrate max 25 m/min
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Control PC control
Total connection 5,5 kW
Space requirement Length 2,2 m
Space requirement Width 1,4 m
Space requirement Height 1,6 m
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
