Year of manufacture 2021
Working dimension X 5.420 mm
Working dimension Y 1.350 mm
Working dimension Z 210 mm
Number of milling spindles 1
HOLZ-HER ChipControl
HOLZ-HER 5-axes spindle 7844
Main motor power 13 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 33
HOLZ-HER Tool changer 7996
HOLZ-HER Tool changer 7892
HOLZ-HER Tool changer 7886 Pickup tool changing position
Vertical drilling spindles 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
HOLZ-HER Drilling aggregate 7882
Cantilever machine
Machine table Pod and rail table
Two rows of stops
Workpiece support aids
Electronic supervision of the end-position of the stops
Number of consoles 8
Pneumatic pipe connectors zentral
4-field processing
Positioning aid
Crosshair laser
Vacuum pump
HOLZ-HER ECO-Vac
Number of vacuum pumps 2
Capacity vacuum pump 275 m³/h
Special workpiece clamping system For windows
Safety device Safety mat
Chip conveyor
Interface for .dxf data
Control cabinet cooling
Automatic central lubrication
Control PC control
Conformity marking CE mark
Weight 6.500 kg
Space requirement Length 9 m
Space requirement Width 4,7 m
Space requirement Height 2,8 m
