Year of manufacture 2012
Working width 300 mm
Planing height 200 mm
Number of spindles 5
Bottom spindles 2
Right spindles 1
Spindles left 1
Spindles top 1
Spindle configuration b-r-l-t-b
Spindle rotation speed max 1/min 6.000 rpm
Spindle diameter 50 mm
Feedrate max 36 m/min
Continuously variable feed
Feed motor 9,5 kW
Main motor power 22 kW
Saw shaft
Saw shaft 22 kW
Jointing technology straight jointer
Spindle(s) with counterbearing
Hydraulic clamping
Seperate motor per spindle
Motoric adjustment Programmable controller
Surface of the machine table hard-coated
Infeed table length 1.200 mm
Table rollers driven
Lubrication pump automatic
Pneumatic top pressure
First infeed roller controlled
Type of feed roller drive Cardanic
Chamfering aggregate
CNC-axes Yes
Anti-kickback saftey device
Control WEINIG MEMORY PLUS-SYSTEM
Conformity marking CE mark
Memory Plus
Kickback Protection
Without planer heads
1. Bottom Spindle 11 kW with counter bearing
Tool cutting circle: 150–180 mm
Axial adjustment: 17 mm (possible even with the counter bearing closed)
Requires a hydro cutterhead
2. Right Spindle 11 kW
Tool cutting circle: 112–250 mm
Maximum profile depth: 35 mm
Axial adjustment range: 80 mm
3. Left Spindle 11 kW
Tool cutting circle: 112–232 mm
Maximum profile depth: 35 mm
Axial adjustment range: 80 mm
Pneumatic side roller pressure
4. Top Spindle 15 kW with counter bearing and pneumatic clamping
Maximum profile depth: 35 mm
Tool cutting circle: 150–250 mm
Axial adjustment: 45 mm (possible even with the counter bearing closed)
JOINTER for straight knives and tools with a diameter of 150–163 mm
Remote control, automatic stone feed (Steinzustellung) working width up to 300 mm
Requires a hydro cutterhead
Chamfering Unit (FASEAGGREGAT) 1.1 kW
Shaft diameter: 16 mm
12,000 rpm
Tool cutting circle: 80 mm
Automatic adjustment together with the left spindle
5. Bottom Spindle 22 kW with counter bearing (can also be used as a saw shaft)
Maximum profile depth: 15 mm
Tool cutting circle: 150–250 mm
Axial adjustment: 45 mm (possible even with the counter bearing closed)
JOINTER for straight knives and tools with a diameter of 150–163 mm
Remote control automatic stone feed working width up to 300 mm
Table plates for wooden inserts and an additional discharge plate above the spindle
Requires a hydro cutterhead
Unless expressly stated, tools or other accessories and parts that may be shown in photos and videos are not included in the scope of delivery.
