CONTROL SYSTEM
• NC 1000 numerical control on PC basis
TECHNICAL FEATURES
• Useful working field (x – y - z): approx. 3,432 x 1,300
• Piece passage: approx. 155mm
PANEL SUPPORT AREA
• Nr. 8 ATS worktops to support panels with digital display - nr. 24
carts
• Nr. 8 Bar lifters with pneumatic positioning
• Nr. 1 Vacuum pump 100 m³/h
DRILLING/GROOVE GROUPS
• Nr. 1 complete boring head:
- no. 20 independent spindles for vertical drilling (nr. 10 in “X, nr. 10 in “Y”)
- no. 4 independent spindles with double output for horizontal drilling (nr. 3+3 in “X”, nr. 1+1 in “Y”)
• Nr. 1 independent spindles with double output for horizontal drilling in the "Y" direction
• Nr. 1 circular blade dia 160 mm 0°-90° from CN
MILLING GROUP
• Nr. 1 7.5 kW (10.2 HP) air-cooled ISO 30 electrospindle
• Nr. 1 air-cooled 9 kW (12.2 HP) ISO 30 electrospindle
• Nr. 1 Chain tool change magazine with nr. 21 positions
PREPARATIONS AND ACCESSORIES
• Chip conveyor belt
REGULATIONS AND OPTIONALS FOR SAFETY
• Copy of the original CE Declaration of Conformity
• Electronic front safety mats
• Side safety grilles
- Italy
- Second hand
