Year of manufacture 2016
Workpiece return Conveyor belt
Edgeband thickness max 20 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 100 mm
Feed min 18 m/min
Feedrate max 24 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Places in coil magazine 6
Glue system granulate Premelting unit
BIESSE Glue system SP 10
Suitable for PUR glue
BIESSE ARTECH Glue system gPoD
PUR Aufschmelzeinheit externer PUR-Aufschmelzer
Magazine for single strips
Spraying device
Spraying device Release agent
Spraying device Lubricant
Spraying device Cleaning agent
Premilling unit
BIESSE Premilling unit RT 30
Andruckzone NC-gesteuert
Trimming saw 2 motors
BIESSE EDGE Trimming saw IT 90-S
Flush/radius/chamfer milling units 2
BIESSE EDGE Flush milling unit RS 10
BIESSE Fine milling unit RF 30
Corner rounding unit 4 motors
BIESSE EDGE Corner rounding unit AR 34
Nutfräsaggregat Universalfräsaggregat schwenkbar
BIESSE Universal milling aggregate EB 40
Scraper unit Profile scraper, Flat scraper
BIESSE Profile scraper unit RB 40
BIESSE Flat scraper unit RC 20
Suitable for nesting Bündig/Radius/Fasestationen, Profile scraper
Buffing unit
BIESSE Buffing unit SZ 30
Aggregates actuated by control NC-axes, pneumatic
Profilwechsel automatisch Bündig/Radius/Fasestationen, Profile scraper
Quick-change aggregates Nutfräsaggregat
ISO 30
Type right-side machine
Machine length 10.140 mm
Narrow-part infeed
Barcode reader
Automatic lubrication
UPS - Uninterruptible Power Supply
Air cushion table
Control CNI SINTRA, PC control
Software MICROSOFT WINDOWS 7
Conformity marking CE mark, EAC mark
Total connection 35 kW
Weight 7.890 kg
