Year of manufacture 2022
Working dimension X 3.200 mm
Working dimension Y 1.250 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 6,5 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 8
Number of exchangeable units 1
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system Pressure rollers, clamp gripper
Barcode reader
Dowel insertion
Glue system Water dowel
Safety device enclosed cabin
Barcode reader
Control cabinet cooling
Control BIESSE bTouch
Conformity marking CE mark
Total connection 21 kW
Weight 2.500 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
