Year of manufacture 2022
Working dimension X 4.300 mm
Working dimension Y 2.205 mm
Working dimension Z 170 mm
Number of milling spindles 1
Main motor power 13,2 kW
Rotation speed max 24.000 rpm
Torque support
Tool clamping system HSK-F63
Tool changer positions 16
Vertical drilling spindles 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Gantry machine Yes
Machine table Matrix table
Outfeed discharge unit, Conveyor belt
Safety device Bumper
BIESSE Drilling aggregate BH 17 L
BIESSE Sweeping Arm
Handheld terminal
Blow-off device
UPS - Uninterruptible Power Supply
Control BIESSE BH 660
Software BIESSE B_SOLID
Conformity marking CE mark
Weight 4.100 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
