Year of manufacture 2018
Working dimension X 4.300 mm
Working dimension Y 2.205 mm
Working dimension Z 250 mm
Number of milling spindles 1
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 12
Gantry machine Yes
Machine table Matrix table
Vacuum pump
Capacity vacuum pump 500 m³/h
Suitable for nesting
Feeding Lift table
Outfeed Conveyor belt
Safety device Bumper, Light barrier, Safety mat
Interface for .dxf data
BIESSE Sweeping Arm
Disc tool changer
Multi-zone vacuum
Blow-off device
Tool charge measurement
Milling spindle liquid-cooled
Automatic central lubrication
Software BIESSE B_SOLID, BIESSE SOPHIA
Conformity marking CE mark
