Year of manufacture 2008
Working dimension X 2.510 mm
Working dimension Y 1.250 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 6 kW
Rotation speed max 18.000 rpm
Tool clamping system ETP 25
Vertical drilling spindles 8
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 6
Vacuum pump
Capacity vacuum pump 100 m³/h
Safety device Light barrier
Software HOMAG WOODWOP 5.0
Declaration of CE-conformity
Conformity marking CE mark
Total connection 14 kW
Weight 3.200 kg
Space requirement Length 4,83 m
Space requirement Width 3,6 m
Space requirement Height 2,2 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
