Year of manufacture 2011
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece width min 55 mm
Feed min 12 m/min
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Places in coil magazine 1
Zero joint Laser technology
HOMAG Activation unit laserTec
Glue system granulate Premelting unit
HOMAG Glue system A 20 Gluing unit
Magazine for single strips
Spraying device
Release agent
Cleaning agent
Premilling unit
HOMAG Premilling unit S 2
Trimming saw 2 motors
HOMAG Trimming saw HL 86
Flush/radius/chamfer milling units 1
HOMAG
Corner rounding unit 2 motors
HOMAG Corner rounding unit FK 13
Tool changer positions 8
Scraper unit Profile scraper, Flat scraper
HOMAG Scraper unit MN 21 AUTOMATISCH Multi-cleaning
HOMAG Flat scraper unit FA 11 Polishing aggregate
Buffing unit
Free spaces for aggregates 1
Aggregates actuated by control NC-axes
Type right-side machine
Quick-change aggregate(s)
Machine length 10.200 mm
Scissor support
Infeed barrier
HOMAG infeed fence with automatic adjustment
Narrow-part infeed
HOMAG Edge control
Control powerControl PC 22, Touchscreen
Software SCHULER MDE PROFESSIONAL, HOMAG WOODSCOUT
Conformity marking CE mark
