Sanding width 1.600 mm
Workpiece thickness min 3 mm
Passage height max 150 mm
Sanding aggregates total 3
Sanding rollers 1
Steel roller
Sanding pads total 1
Jump-in control
Segmental pressure pad electronic
Jump-in control electromagnetic
Sanding brush unit Disc brush unit
Cleaning brush Yes
Chevron belt unit longitudinal
Lacquer sanding
Vacuum table
Vacuum fan
Constant passline height
Main motor power 30 kW
Sanding belt length 2.620 mm
Belt speed max 24 m/s
Adjustable sanding belt speed continuously variable
Aggregates with frequency inverters 1
Feedrate max 25 m/min
Continuously variable feed
Blow-off device Workpieces, Sanding belt
Configuration of aggregates r-p-u-u
Side of belt change Left
HEESEMANN Segmental pressure pad CSD
HEESEMANN DB-S Planetary unit
HEESEMANN Blasting system
Protection against workpiece over-thickness
Control HEESEMANN INDUSTRIE PC
https://www.hoechsmann.com/12438
2024-10-10 10:38:23
- Germany
- Second hand
