Year of manufacture 2019
Workpiece return No
Edgeband thickness max 3 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 100 mm
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Glue system granulate Premelting unit
Suitable for PUR glue
Spraying device
Premilling unit
Preheating zone
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 4 motors
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control pneumatic, NC-axes
Type left-side machine
Machine length 9.140 mm
Suitable for nesting Yes
BIESSE Premilling unit RT 20
BIESSE Glue system SP 10
NORDSON Glue system EB 60
BIESSE Trimming saw IT 90-P
BIESSE Fine milling unit RF 30
BIESSE Corner rounding unit AR 34
BIESSE Profile scraper unit RB 40
BIESSE Flat scraper unit RC 20
Control PC control
Software BIESSE SOPHIA, CNI SINTRA
Declaration of CE-conformity
Conformity marking CE mark
Total connection 34 kW
Weight 5.500 kg
Nesting rollers for the flat scraper
https://www.hoechsmann.com/16581
2024-11-12 12:53:37
- Germany
- Second hand
