* working width 230 mm
* working height 125 mm
* vertical heads on one engine with a power of 7.5 kW
* horizontal heads on separate motors with a power of 5.5 kW each
* total power approx. 20 kW
* 40 mm diameter spindles
* electric adjustment of the body and rollers up / down
* starting engines 0-1
* adjustable feed speed on the inverter
* 4 adjustable spindles in two axes
* vertical heads adjustable up / down and front / back (as in a milling machine)
* 4 heads for traditional knives included (new)
* introductory rack in front of the first head
* pneumatic and adjustable pressure of the drawing rollers
* table top, 247 cm long and 23 cm wide, in perfect condition
* foot pump to lubricate the table top
* soundproofing cabin
* main extraction connector fi 250 mm (internal 4 x 120 mm)
* weight approx. 1,600 kg
* 1998 year of production
* meets CE standards
* overall dimensions 355 x 120 x 165 cm (length x width x height)
In the link below you will find more photos in full quality:
drive.google.com/drive/folders/1DWf0Lm-rNtmKRTraHCUQDiQXOGAtj5RM?usp=sharing
