Configuration and Parameter
Working area 2100*2800mm
Thickness of machinable material ≤50 mm
Travel speed X/Y/Z 80m/min; 80m/min; 20m/min
Repeatability precision ±0.05mm
Working speed 0~20m/min
Voltage 380V 3Phase 50HZ
Air pressure ≥ 6.5Kgf/cm
Machine body Heavy duty bed, welded 10 mm thick steel tubing
heat treated and sandblasted
Spindle Italy HSD ES951 9.6KW/ Hiteco 9.5KW
ATC air-cooled spindle 24000rpm
Tool magazine 12-bit carousel tool magazine
Variable frequency drive Hpmont 11KW
Control system Taiwan Syntec 60CB
with mouse, keyboard and hand-wheel
Software
Servo motor Japan Yaskawa servo motor
Y: 1.3KW X:850W Z:850W
Reducer Japan Shimpo
Transmission X, Y-axis helical rack, Z-axis ball screw
Helical rack Germany Rotalin 2M
Linear guide rail Taiwan T-win
X,Z H25; Y H35
Work table PVC+ vacuum cavity of steel plate
Vacuum pump Germany Becker 5.5KW 2 sets
Press roller Prevent material deformation
Dust collector 5.5KW double bag
with dust hood, vacuum pipe and bracket
Lubrication pump Timed and quantitative lubrication
Spindle cover Safe protective cover
Pop up pins For positioning materials
Electrical components Schneider
Pneumatic components Taiwan Airtac
Safety switch Siemens
Electric cable Highly flexible anti-shielded cable
Leveling feet Leveling machine
Accessory ISO30 tool holder, drill bits, ER32 collets, etc
