• Machine number 1680,
• 380V, 50Hz, 86kW,
• max. machining length in X-axis 2500 mm,
• Stroke of units A, B, C, D, U, V, W,
• Z axis 370 mm,
• Inclination of the work tables on the respective axes -10°, 0°, 10°,
• max. vertical travel of the spindle 20 mm,
• Spindle diameter 40 mm,
• max. size of tools:
• Diameter x height 160 x 180 mm,
• Sandpaper size L x H 2360:2400 x 180 mm,
• Spindle rotation number 1-A 2-B= 8500 rpm,
• Number of revolutions spindle 3-C 4-D 5-U 6-V 7-W 8-Z= 500:8500 rpm,
• total installed power 120 kW, air pressure 6 bar,
• max. machining length with standard rounding 250 mm,
• max. processing width with rounding 500 mm,
• max. processing height 180 mm,
• Speeds max. feed of the table 30 m/min,
• max. return thrust of the table 100 m/min,
• max. acceleration of the aggregates 5 m/sec²,
• Aggregates
• 1+1 milling units with 15 HP engines,
• 1+1 milling units with 10 HP motors,
• 1+1 milling/grinding units with dual polarity motors 6.5 to 4 HP,
• 1+1 grinding units with 4 HP motors,
• Tensioner, pneum. secured against rotation, tiltable, 8, stops, pneum., 8,
• OSAI control,
• Weight approx. 750 kg,
• Machine housing packing dimensions 4000 x 2400 x 2000 mm,
• Weight approx. 1500 kg
- Poland
- d'occasion
